Minimum Asphalt Paving Process Road Surfacing Machine , 7 Separate Units Asphalt Transfer Machine

Basic Information

Certification:	CE/CNAS/SGS/ISO
Model Number:	ARHR-5120A

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	nude packing/bulk ship/ro-ro ship
Delivery Time:	2 month after received down payment/negotiation
Supply Ability:	5 sets per month

Get Best Price Contact Now

Detail Information

Heating Method:	Circulation Of Hot Wind	Application:	Single Lane
Daily Construction Length:	Above 2KM	Mobile Units:	7
Fuel Type:	Diesel	Heating Layer:	2
Maintained Pavement Thickness:	4~6CM	Speed:	2-5M/ Minute
Highlight:	road surfacing machine , road paving equipment

Product Description

Minimum asphalt aging hot in place asphalt recycling machine / road paving machinery composed of 7 separate units

Description:

Analysis and evaluation based on existing maintenance technology

Pavement structure of semi-rigid base course, with characteristics of high strength and load diffusion capacity, is currently widely used on national highway, provincial and national main roads. Typical damages from this type of pavement are rutting, crack and water damage. Against those damages, maintenance methods are repaving after milling, micro-surfacing and hot in-place recycling, etc.

1. Milling&repaving

Applicable to all kinds of damage, a most common maintenance mode.

Advantage: common and completely treated.

Disadvantages: huge construction quantities, high cost, long construction period, traffic organization problem to high traffic expressway and big resource losses, which don’t meet the development concept of “Green, Low-carbon, Environmental Friendly”.

2. Micro-surfacing

A kind of preventative maintenance technology and suitable for slight damages on pavement surface, normally applied to performance recovery of pavement surface.

Advantage: fast and economic

Disadvantages: only suitable to preventative maintenance at early stage of pavement surface, low durability, big traffic noise, and its structure depth and anti-slide performance would decrease after certain period, difficult to control construction quality, leading to early-stage stripping, which is totally of low cost performance.

Minimum Asphalt Paving Process Road Surfacing Machine , 7 Separate Units Asphalt Transfer Machine

No.

Name

Remark

Original pavement heater (2 units)

Function: Heating original pavement

Heating tank length:3.75 M

width: 2.5M—4M adjustable

Heating temperature: 350℃--550℃ adjustable

Construction speed:1.5M—5M /min

Transition speed:10KM /hour

Automatic lifting: automatic loading and unloading, transporting; no need lifting device

DIM: 13400×3000×3340mm

=134.268M³/unit

135 M³

Original pavement miller

Function: heating, milling, regerant and asphalt adding

Heating tank length: 8 M width: 4M

Heating temperature: 350℃--550℃ adjustable

Milling width:3 M—4 M adjustable

Construction speed:1.5M—5M /min

Running speed:10KM /hour

DIM:12000×3150×3250mm

123 M³

Channel heater/road trough heater

Function: Heating the original pavement

Heating tank length:3.75 M

width: 2.5M—4M adjustable

Heating temperature: 350℃--550℃ adjustable

Construction speed:1.5M—5M /min

Transition speed:10KM /hour

Automatic lifting: automatic loading and unloading, transporting; no need lifting device

DIM: 13400×3000×3340mm

Channel pavement miller

Function: heating, milling, regerant and asphalt adding

Heating tank length: 8 M width: 4M

Heating temperature: 350℃--550℃ adjustable

Milling width:3 M—4 M adjustable

Construction speed:1.5M—5M /min

Running speed:10KM /hour

DIM:12000×3150×3250mm

Double layer heater

Function: asphalt mixture adding and heating

Asphalt mixture adding: precise control according to the set formula

Heating tank length: 6 M width:4 M

Double layer heating: upper and lower layer heating, fast temperature increasing of the mixture, good effect

Automatic loading and unloading

DIM: 14755×3200×3250mm

154
