Twice Weighing Method Portable Asphalt Plant , 160tph Automatic Batching Plant

Twice weighing method 160tph mobile asphalt mixing plant driven by trailer truck

Description of filler tank mobile unit and asphalt heating mobile unit

1, filler tank mobile unit

1.1 Fine material storage supply system (mobile system)

Mineral storage bin screw conveyor and accessories are mounted on one semi-trailer.

1.2 Mineral powder storage

Type: vertical tube structure

volume: 30m³

1.3 Storage accessories

Indicator: one piece

Hand valve: one piece

Air filter: one piece

Pressure busting: one set

1.4 Screw conveyor

Conveyor capacity: 30t/h

2.0 Asphalt heating system

30m³ horizontal asphalt tank, thermal oil furnace and asphalt pump are mounted on one semi-trailer.

2.1 20m³ Horizontal asphalt tank: 1sets

Used for storage and heating asphalt, and thermal oil heating. There are two outlet nozzles.

Circle horizontal tank with handrail, asphalt pipeline, exhaust pipeline, to heat exchange as thermal oil pipeline, the area according to the tank, outward floating liquidometer, tons indicator, dual-metal thermometer, high-efficiency heat-proof tank adopt rock cotton as the insulating material, the appearance adopts color steel cover.

Asphalt pump send asphalt in storage to weighing silo, and there is pneumatic three-way valve inside the storage.

Heating type: Thermal oil

Tank volume: 20m³

2.2 Thermal Oil Furnace

It had a outward operation cabinet as a free operation part, ring thermal oil pipe is in the oil furnace as heat exchange media, outside covers color steel plate, full auto burner ,heat oil pump, high expand channel.

Type of thermal oil furnace: QXM-50

Heat supply capacity: 500,000k/h

Max working temperature: 260℃

Power of heat oil pump: 15kw

Function of burner: Full auto ignition & monitor, fuel temperature control, trouble auto alarm

Control system: Auto control, to reach full auto monitor and operation for temperature, heat oil cycle, oil level, oil pressure, etc. auto alarm, burner auto shutdown.

Configuration includes:Pipes, Valves, flanges, metal bushes necessary for all pipelines of thermal oil and asphalt.

2.3 50m3 Horizontal asphalt tank: 1sets

Used for storage and heating asphalt, and thermal oil heating.

Heavy tube horizontal tank with handrail, asphalt pipeline, exhaust pipeline, to heat exchange as thermal oil pipeline, the area according to the tank, outward floating liquid meter, tons indicator, dual-metal thermometer, high-efficiency heat-proof tank adopt rock cotton as the insulating material, the appearance adopts color steel cover.

Heating type: Thermal oil

Tank volume: 50m3
