| Place of Origin: | China |
|---|---|
| Brand Name: | Xitong |
| Certification: | CE/CNAS/SGS |
| Model Number: | QLB |
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Packaging Details: | Container |
| Delivery Time: | negotiation /2 month after contract signed |
| Payment Terms: | T/T or LC |
| Supply Ability: | 8 set per month |
| Model Number: | QLB-2000 | Type: | Stationary |
|---|---|---|---|
| Production Capacity: | 160t/h | Warranty: | 1 Year |
| Equipment Color: | Light Sky Blue | Manufacturing Standard: | European CE |
| Condition: | New | Burner Fuel: | Diesel, Mazut, National Gas |
| High Light: | Asphalt drum mixing plant,Asphalt drum mixer plant |
||
1. The vibration screen processed through sheet cold riveting technique from USA enhances the structure reliability to make it run smoothly and increase
2. Adopt special lifting-blade structure of dryer to ensure the fuel burn sufficiently and make thermal efficiency improve more than 8%(frequency stepless control device of dryer, national petent No.ZL200420028145.4)
3. The two- step(secondary) dust collecting system meets European emission standards. Effective area of Nomex bag filter reaches up to 98%.Dust separation efficiency no lower than 85%.Volute casing collector, national patent(ZL200520069727.1)
4.Imported brand burner suitable to different fuels(oil,gas, coal powder), provided various choice for clients
Performance of burner
1, Large regulating ratio 1:10,start smoothly,extremely high temp control accuracy.
2, When power keeps unchanged, shape of fire could be adjustable, solving the problem of being unable to move the temperature area, and therefore realizing a best match to any types of dryer.
3, With excellent anti-resistance of air flow(gas) and loading pressure performance, suitable for various working conditions and circumstances, meanwhile with low requirements against working condition
4, Frequency control is included in PLC control, mechanical ratio control, multi-control and intelligent control, to reduce electricity consumption.
5,The burner adopts internal recycle system to charge oil safely, and saves fuel through one-time heating.
5. The mixing tank is vortex mixing type adopting special anti-abrasive material. The outside of mixing tank sheel has the thermal oil heating function, which has upgraded the mixing quality of asphalt mixture to a new level.
6. Adopt the screw conveyor made by Italian WAM company, which greatly increase the measurement precision of mineral powder and reclaimed powder
7, Have National Academician workstation from Chinese Academy of Engineering, product design, research and develop with assistance and guide of its member.
8 , Main components from German, Italy, Japan, Etc.
9, Outstanding insulation system to enhance thermal efficiency and output
10, Multilingual language operating System provides better humanized experience/ console supports multilingual language like English , Russia, Arabic,etc.
